Aruba Instant On AP11D Desk / Wall Access Points - White

CertificationsUL 2043 plenum rating EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE)

Input VoltagePower over Ethernet (POE) on E0: 802.3af (class 3) or 802.3at (class 4). When using 802.3af, POE-out on E3 is disabled DC power (48V): no restrictions Power sources are sold separately.

Wi-Fi AntennaIntegrated directional antennas with a maximum individual antenna gain of 4.3dBi in 2.4GHz and 6.2dBi in 5GHz.

ConnectivityIEEE 802.11ac, 802.11n

External I/O Ports(1) uplink Gigabit Ethernet port (E0), with POE-in support (802.3at/802.3af) (3) downlink Gigabit Ethernet ports (E1-E3), with POE-out on E3 (802.3af)

MountingThe access point ships with a single gang wall-box mount kit and desk mount kit.

Weight (metric)313 g

Product Dimensions (metric)150 x 86 x 40 mm
