| Brand |
Synology |
| Model |
Synology DiskStation DS920+ |
| CPU Model |
Intel Celeron J4125 |
| CPU Frequency |
Quad-Core 2.0 (base) / 2.7 (turbo) GHz |
| Hardware Encryption Engine |
Yes (AES-NI) |
| System Memory |
4 GB DDR4 non-ECC |
| Memory Slots |
1 |
| Memory Expandable |
8 GB (4 GB + 4 GB) |
| Hard Drive Installed |
3TB / 3x 1TB SATA HDD |
| Hard Drive Warranty |
One Year |
| Storage Drive Bay(s) |
4 |
| Maximum Drive Bays with Expansion Unit |
9 |
| M.2 NVMe Drive Slots |
2 |
| Compatible Drive Type |
3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe SSD |
| Maximum Single Volume Size |
108 TB |
| Hot-Swappable Drive |
Yes |
| Supported RAID Type |
Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| External Ports |
USB 3.0 ports x 2, eSATA Port x 1 |
| File System |
Internal: Btrfs, EXT4 / External: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+ |
| LAN |
(RJ-45) x 2 (with Link Aggregation / Failover support) |
| System Fan |
92 mm x 92 mm x 2 pcs |
| Fan Speed Mode |
Full-Speed Mode, Cool Mode, Quiet Mode |
| Noise Level |
19.8 dB(A) |
| Power Recovery |
Yes |
| Power Supply Unit / Adapter |
100W |
| AC Input Power Voltage |
100V to 240V AC |
| Power Frequency |
50/60 Hz, Single Phase |
| Power Consumption |
32.17 W (Access), 9.69 W (HDD Hibernation) |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
| Relative Humidity |
5% to 95% RH |
| Certification |
FCC, CE, BSMI, EAC, CCC, KC, VCCI, RCM |
| Dimensions (W x D x H) |
199 x 223 x 166 mm |
| Weight |
2.24 kg |
| Warranty |
Three Years |
